If general tolerances in accordance with ISO 2768 shall apply, ISO 2768 followed by the tolerance class (Ex: ISO 2768-m) shall be indicated in or near the title block. The following is the tolerance table corresponding to the 4 class precision levels, you can choose the most suitable one according to machining capabilities and your design.
General Tolerances to DIN ISO 2768 The latest DIN standard sheet version applies to all parts made to DIN standards. Variations on dimensions without tolerance values are according to 'DIN ISO 2768- mk'. GENERAL TOLERANCES FOR LINEAR AND ANGULAR DIMENSIONS (DIN ISO 2768 T1).
Iso 2768 Hole Tolerance Table Limits, fits and tolerances calculator has been developed to calculate engineering tolerances of inner and outer features of journal bearings, linear bearings, thrust bearings, bushings, ball bearings, roller bearings, housings, cylinder bores, drilled holes, linear and precision shafts, pistons, etc.
If general tolerances according to ISO 2768-1 are valid, the following has to be inserted in the title box, i.e. For tolerance class medium. ISO 2768 – m or general tolerance ISO 2768 – m. For new designs only the general tolerance according to DIN ISO 2768-1 should be valid.

According to DIN ISO 2768-1

According to DIN ISO 2768-2

General tolerances for linear measures and level squares with four tolerance classes are useful for simplifying drawings.
By choosing the tolerance class precision levels common in workshops should be taken into account.

If smaller tolerances are needed or bigger ones are more economical,
then these tolerances are indicated next to the nominal size.

General tolerances on symmetry Unit: mm Symmetry tolerances for ranges of nominal length Tolerance Up to 100 class Over 100 Over 300 Over 1000 up to 300 up to 1000 up to 3000 General tolerances on symmetry H 0.5 K L 0.6 0.6 1 0.8 1 1.5 2 Table 7. General tolerances on circular run-out Unit: mm Tolerance class Circular run-out. Iso 2768 mk tolerances table Rating: 7,8/10 744 reviews ISO 2768 General tolerances for linear measures and level squares with four tolerance classes are useful for simplifying drawings.

Tabular 1 Limits for linear measures

Tolerance- class	Limits in mm for nominal sizes in mm
Tolerance- class	0,5 to 3	above 3 to 6	above 6 to 30	above 30 to 120	above 120 to 400	above 400 to 1000	above 1000 to 2000	above 2000 to 4000
f (fine)	± 0,05	± 0,05	± 0,1	± 0,15	± 0,2	± 0,3	± 0,5	-
m (medium)	± 0,1	± 0,1	± 0,2	± 0,3	± 0,5	± 0,8	± 1,2	± 2
c (coarse)	± 0,15	± 0,2	± 0,5	± 0,8	± 1,2	± 2	± 3	± 4
v (very coarce grob)	-	± 0,5	± 1	± 1,5	± 2,5	± 4	± 6	± 8

For nominal sizes below 0,5 mm the limit measures are to be indicated directly at the nominal measure.

Tabular 2 Limit measures for radius of curvature and chamfer height

Iso 2768 Mk Tolerance Table Pdf

Tolerance class	Limits in mm for nominal sizes in mm
	0,5 to 3	above 3 to 6	above 6
f (finne)	± 0,2	± 0,5	± 1
m (medium)
c (coarse)	± 0,4	± 1	± 2
v (very coarse)

Bei Nennmassen unter 0,5 mm sind die Grenzabmasse direkt am Nennmass anzugeben.

Tabelle 3 Grenzabmasse für Winkelmasse

Tolerance class	Limits in mm for nominal sizes in mm
Tolerance class	to 10	above 10 to 50	above 50 to 120	above 50 to 400 Wii party u iso download.	above 400
f (fine)	± 1 °	± 30 '	± 20 '	± 10 '	± 5 '
m (medium)	± 1 °	± 30 '	± 20 '	± 10 '	± 5 '
c (coarse )	± 1 ° 30 '	± 1 °	± 30 '	± 15 '	± 10 '
v (very coarce)	± 3 °	± 2 °	± 1 °	± 30 '	± 20 '

For nominal sizes below 0,5 mm the limit measures are to be indicated directly at the nominal measure. If general tolerances according to ISO 2768-1 are valid,
the following has to be inserted in the title box, i.e. for tolerance class medium

ISO 2768 – m or general tolerance ISO 2768 – m

For new designs only the general tolerance according to DIN ISO 2768-1 should be valid. The limit measurements of the tolerance classes m and f of DIN ISO 2768-1 are identic with those of DIN 7168-1.

Iso 2768 Mk Tolerance Table

According to DIN ISO 2768-2

DIN ISO 2768-2 is for simplifying drawing and fixes general tolerances in three tolerance classes for form and position.
By choosing a special tolerance class exactly the precision level common in workshops should be taken into account.

If smaller tolerances are needed or bigger are more economical these tolerances should be mentioned directly according to ISO 1101.

General tolerances for form and position should be used while the tolerance principle according. to ISO 8015 is valid and while this is mentioned in the drawing.
This tolerance principles says that no opposite relation between measure, form and position tolerance exists (principle of superposition).

Tolerance class	General tolerances for straightness and evenness in mm
	Range of specified size in mm
	to 10	above 10 to 30	above 30 to 100	above 100 to 300	above 300 to 1000	above 1000 to 3000
H	0,02	0,05	0,1	0,2	0,3	0,4
K	0,05	0,1	0,2	0,4	0,6	0,8
L	0,1	0,2	0,4	0,8	1,2	1,6
Tolerance class	General tolerances for straightness and evenness in mm
	Range of specified size in mm
	to 100	above 100 to 300	above 300 to 1000	above 1000 to 3000
H	0,2	0,3	0,4	0,5
K	0,4	0,6	0,8	1
L	0,6	1	1,5	2
Tolerance class	General tolerances for symmetry
	Range of specified size in mm
	to 100	above 100 to 300	above 300 to 1000	above 1000 to 3000
H	0,5
K	0,6		0,8	1
L	0,6	1	1,5	2

General tolerances for form and position are valid for form elements for which form and position tolerances are not indicated individually.
They are applicable for all characteristics of the form elements accept cylinders, profiles of any line or surfaces, inclines, coaxiality, position and total movement.
